Overview & Applications / Technical Specifications
| AF/BF Series Filter | |||||
| Model | AF1500 | AF2000 | BF2000 | BF3000 | BF4000 |
| Working medium | AIR | ||||
| Port size | G1/8" | G1/4" | G1/4" | G3/8" | G1/2" |
| Filter precision | 25um(5,50um is optional) | ||||
| Working pressure | 0.95Mpa | ||||
| Guaranteed.pressure | 1.5Mpa | ||||
| Working temperature | 5~60°C | ||||
| Filter bowl capacity | 15(CC) | 60(CC) | |||
| Weight | 0.14kg | 0.33kg | |||
| Material | Body | Aluminum Die-casting Forming | |||
| Container Cup | PE | ||||
| Protective Cover | Iron |
Features:
1. Temperature Range: 5-60 Degree
2. Max. Pressure of 0.95 Mpa
3. Body Material: Aluminum Die-casting Forming
4. Prepares Air Properly For All Types Of Compressed Air Tools And Equipment
5. The Filter Removes Solid Particles And Condensates With Compressed Air
Specifications:
